Contributor Training: Tmate for Debugging GitHub Actions Workflows

Randy Fay avatar
Randy Fay

October 23, 2024 5 min read

Edit this page
Detective Inspector studying GitHub tests

Here’s our October 23, 2024 Contributor Training on using ddev debug test to help other users:

What is Tmate?

mxschmitt/action-tmate provides a way to ssh into actual running GitHub Actions VMs to debug your tests.

Why do we need Tmate?

Often it’s hard to understand what has happened with an test because all we see in GitHub’s web UI is the output, and we can’t interact with it. And trying to recreate the test environment is sometimes fine, but sometimes it’s hard to recreate the test. GitHub runners have different memory configuration, disk space, and different packages installed, and they’re typically running AMD64 Ubuntu, which may not be something we have easy access to.

Alternatives to Tmate

  1. We normally will try to understand a test failure by running it locally.
  2. Running in a similar Linux/AMD64 system like Gitpod is a pretty easy option.
  3. nektos/act is another recommended competitor to Tmate. It uses Docker and a Docker image to run an action on your local machine. I haven’t had luck with it when I’ve tried it. See Stas’s experience with act below.

Security Concerns

If your test has secrets, then anyone who can ssh into it has access to those secrets.

In addition, the owners of ssh.tmate.io clearly have access to the ssh session you’re experimenting with, so think carefully about secrets that might be exposed. (In many tests, there are no secrets likely exposed or available. We have a couple of DDEV GitHub actions that have sensitive secrets, and a few more that have far-less sensitive secrets.)

I recommend always using limit-access-to-actor: true so that only the user that has launched the test can ssh into it.

Usage Examples

These examples are all at rfay/tmate-demos, which you can fork and experiment with to your heart’s delight.

Basic on-push example with tmate running after the work is done

This on-push example just does some work (sets up DDEV and a Drupal project) and then right after that the Tmate action starts up and starts telling you how to SSH into the test.

Detached example, where Tmate starts at the end

In the detached example Tmate is set up early in the workflow, but is set to detached: true, so doesn’t become active until everything else is done. However, if there’s an error, we won’t get to the Tmate step this way.

Failure Example

Often we have a complex step and want to be able to debug it if it fails. For this we can used if: ${{ failure() }}, as shown in the failure example. Tmate kicks in automatically if the step before it fails. It would be nicer if it kicked in on any failure, but it just kicks in when the step before fails.

Workflow Dispatch Example

The Workflow Dispatch is one of my favorite techniques, because you can easily restart the workflow as many times as you like, and choosing whether to invoke Tmate is just a click of a checkbox.

How to Use Act

nektos/act offers a way to locally simulate GitHub Actions workflows.

In this example .github/workflows/jekyll-gh-pages.yml, we deploy Jekyll to GitHub Pages with dynamic addition of JSON data to the website. Our focus is to debug the API call to GitHub using JavaScript:

name: Deploy Jekyll with GitHub Pages

on:
  push:
    branches: [main]
  workflow_dispatch:

permissions:
  contents: read
  pages: write
  id-token: write

concurrency:
  group: "pages"
  cancel-in-progress: false

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout
        uses: actions/checkout@v4
      - name: Setup Pages
        uses: actions/configure-pages@v5
      - name: Build with Jekyll
        uses: actions/jekyll-build-pages@v1
        with:
          source: ./
          destination: ./_site
      - name: Get GitHub repositories
        uses: actions/github-script@v7
        with:
          github-token: ${{ secrets.GITHUB_TOKEN }}
          script: |
            const { data } = await github.rest.search.repos({q: 'user:stasadev'})
            console.log(data)
            const fs = require('fs');
            fs.writeFileSync('data.json', JSON.stringify(data, null, 2));
      - name: Add JSON files to the site
        run: |
          cat data.json | sudo tee ./_site/data.json
      - name: Upload artifact
        uses: actions/upload-pages-artifact@v3
  deploy:
    environment:
      name: github-pages
      url: ${{ steps.deployment.outputs.page_url }}
    runs-on: ubuntu-latest
    needs: build
    steps:
      - name: Deploy to GitHub Pages
        id: deployment
        uses: actions/deploy-pages@v4

  1. Simplify the workflow file .github/workflows/jekyll-gh-pages.yml by removing unrelated code to focus on testing the API call:

    jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - name: Get my GitHub repositories
        uses: actions/github-script@v7
        with:
          github-token: ${{ secrets.GITHUB_TOKEN }}
          script: |
            const { data } = await github.rest.search.repos({q: 'user:stasadev'})
            console.log(data)
            const fs = require('fs');
            fs.writeFileSync('data.json', JSON.stringify(data, null, 2));

    This workflow retrieves repositories for a specified user, writes them to data.json, and outputs the result with console.log().

  2. Run the workflow locally with act in your project’s root directory:

    act -P ubuntu-latest=catthehacker/ubuntu:act-latest \
    --bind \
    --job build \
    -s GITHUB_TOKEN=my_token
    • -P ubuntu-latest=catthehacker/ubuntu:act-latest: Specifies the Docker image to use for the ubuntu-latest environment. If not specified, act uses the default image from its .actrc file (see GitHub issue for more details).
    • --bind: Mounts the current working directory into the container, allowing files generated in the container (like data.json) to be accessible in the host file system.
    • --job build: Tells act to run only the build job from the workflow.
    • -s GITHUB_TOKEN=my_token: Sets a secret (GITHUB_TOKEN) for the workflow, where my_token should be replaced with a valid GitHub token for authentication.

The primary advantage of using act in this context is the ability to efficiently debug API calls locally in just a few seconds, without the need to commit changes, push them to GitHub, and wait for the workflow to complete, which typically takes several minutes.

Contributions welcome!

Your suggestions to improve this blog are welcome. You can do a PR to this blog adding your techniques. Info and a training session on how to do a PR to anything in ddev.com is at DDEV Website For Contributors.

Join us for the next DDEV Live Contributor Training. Sign up at DDEV Live Events Meetup.
